The lamp has a good heat dissipation effect, suitable for all kinds of explosion-proof requirements of ships, oil mining platforms, chemical and with explosive gases 1 or 2 area lighting, this lamp can be safely and reliably used in explosive mixture of substances IIA, IIB, IIC explosive air mixture of substances in the place.
Material Stainless Steel/Copper
Explosion-Proof Marking (Gas) Ex db eb mb IIC T5/T6 Gb
Explosion-Proof Marking（Dust） Ex tb IIIC T95/80℃ Db
Dimension 311 × 216 × 176.5 mm
Degree Of Protection IP66
Ta -40℃ ~ +55℃
Light Source Led Modules
Service Life ≥50000h
Luminous Flux 12500 lm
Rated Voltage AC110V ~ AC277V
Rated Power 100W
Material Stainless Steel/Copper
Explosion-Proof Marking (Gas) Ex db eb mb IIC T5/T6 Gb
Explosion-Proof Marking（Dust） Ex tb IIIC T95/80℃ Db
Dimension 302 x 350 x 176.5 mm
Degree Of Protection IP66
Ta -40℃ ~ +55℃
Light Source Led Modules
Service Life ≥50000h
Luminous Flux 25000 lm
Rated Voltage AC110V ~ AC277V
Rated Power 250W
Material Stainless Steel/Copper
Explosion-Proof Marking (Gas) Ex db eb mb IIC T4/T5 Gb
Explosion-Proof Marking（Dust） Ex tb IIIC T130/95℃ Db
Dimension 604 x 356 x 186 mm
Degree Of Protection IP66
Ta -40℃ ~ +55℃
Light Source Led Modules
Service Life ≥50000h
Luminous Flux 50000 lm
Rated Voltage AC110V ~ AC277V
Rated Power 500W
