LTH is a LED navigation light designed for extreme low temperature environment, suitable for 50 meters or more than 50 meters transportation ships for night navigation, light signal identification, contact. The combination of advanced optical design and protection technology ensures that it can operate stably in harsh environments from -50°C to +50°C. It is widely used in ships, offshore platforms, polar research equipment and outdoor facilities in high-cold areas.
Material Stainless Steel+Glass
Dimension 256 × 170 ×183 mm
Weight 7 kg
Degree Of Protection IP66
Ta -50℃ ~ +50℃
Light Source LED
Service Life ≥50000h
Range Of Visibility 3 n.m
Horizontal Sector 112.5°
Colour Of Light Green
Rated Voltage DC24V / AC110V / AC220V
Rated Power 2 × 8.5W
Material Stainless Steel+Glass
Dimension 256 × 170 ×183 mm
Weight 7 kg
Degree Of Protection IP66
Ta -50℃ ~ +50℃
Light Source LED
Service Life ≥50000h
Range Of Visibility 3 n.m
Horizontal Sector 112.5°
Colour Of Light Red
Rated Voltage DC24V / AC110V / AC220V
Rated Power 2 × 8.5W
Material Stainless Steel+Glass
Dimension 256 × 170 ×183 mm
Weight 7 kg
Degree Of Protection IP66
Ta -50℃ ~ +50℃
Light Source LED
Service Life ≥50000h
Range Of Visibility 6 n.m
Horizontal Sector 225°
Colour Of Light White
Rated Voltage DC24V / AC110V / AC220V
Rated Power 2 × 15W
Material Stainless Steel+Glass
Dimension 256 × 170 ×183 mm
Weight 7 kg
Degree Of Protection IP66
Ta -50℃ ~ +50℃
Light Source LED
Service Life ≥50000h
Range Of Visibility 3 n.m
Horizontal Sector 135°
Colour Of Light White
Rated Voltage DC24V / AC110V / AC220V
Rated Power 2 × 8.5W
Material Stainless Steel+Glass
Dimension 256 × 170 ×183 mm
Weight 7 kg
Degree Of Protection IP66
Ta -50℃ ~ +50℃
Light Source LED
Service Life ≥50000h
Range Of Visibility 3 n.m
Horizontal Sector 135°
Colour Of Light Yellow
Rated Voltage DC24V / AC110V / AC220V
Rated Power 2 × 8.5W
Material Stainless Steel+Glass
Dimension 256 × 170 ×183 mm
Weight 7 kg
Degree Of Protection IP66
Ta -50℃ ~ +50℃
Light Source LED
Service Life ≥50000h
Range Of Visibility 3 n.m
Horizontal Sector 360°
Colour Of Light White
Rated Voltage DC24V / AC110V / AC220V
Rated Power 2 × 8.5W
Material Stainless Steel+Glass
Dimension 256 × 170 ×183 mm
Weight 7 kg
Degree Of Protection IP66
Ta -50℃ ~ +50℃
Light Source LED
Service Life ≥50000h
Range Of Visibility 3 n.m
Horizontal Sector 360°
Colour Of Light Green / White / Red / Yellow
Rated Voltage DC24V / AC110V / AC220V
Rated Power 2 × 8.5W
